Part identification chart – Weider WEBE0878.0 User Manual
Page 5
5
M8 Locknut (54)
M4 x 15mm
Screw (61)
M8 x 45mm Button Bolt (43)
M8 x 20mm
Button Bolt (64)
M6 x 18mm
Button Screw (50)
M6 Flat
Washer (51)
M8 Flat
Washer (52)
M8 Curved Washer (53)
M8 x 15mm
Button Screw (47)
M8 x 50mm Button Bolt (58)
M6 x 37mm Bolt (65)
M6 Locknut (55)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.
