Weider WEBE0878.0 - Manual (Page 14)

14
7
11
1
2
9
3
10
3
STORING THE INVERSION SYSTEM
To store the inversion system, first adjust the
Adjustment Frame (7) to the shortest length (see
ADJUSTING THE ADJUSTMENT FRAME on page
13). Next, adjust the Ankle Lock (9) to the position
closest to the Adjustment Frame (see ADJUSTING
THE ANKLE LOCK on page 13). Then, lift on the Link
Bars (10, 11, 12) and fold the Front and Rear Legs (1,
2, 3) together.
LOCKING THE INVERSION SYSTEM
When the inversion system is not in use, it should be
locked to prevent unsupervised use. Wrap the Lock
Cable (62) around the Front Leg Frame (5) and the
Adjustment Frame (7) as shown. Then, connect the
ends of the Lock Cable with an M8 x 20mm Button
Bolt (64) and an M8 Locknut (54).
WARNING:
Always make sure that
the Link Bars (10, 11, 12) are straight across
before you use the inversion system.
12
12
62
5
7
64
54
