11
12. Slide the Left Cover (31) onto the left Saddle
Plate (18). Attach the Left Cover with a Small
Knob (42).
Attach the Right Cover (30) in the same
way.
12
30
31
18
42
62
5
7
64
54
WARNING:
HOW TO LOCK THE INVERSION SYSTEM
FOR STORE DISPLAY OR TO PREVENT
UNSUPERVISED USE
When the inversion system is displayed in
a store, or when it is not in use, it should
be locked to prevent unsupervised use.
Wrap the Lock Cable (62) around the Front
Leg Frame (5) and the Adjustment Frame
(7) as shown. Then, connect the ends of
the Lock Cable with an M8 x 20mm Button
Bolt (64) and an M8 Locknut (54).
13. See the inset drawings. Open the Quick
Link (29) by turning the quick link nut.
Then, attach one end of the included Chain
(28) to the indicated bracket on the Front Leg
Frame (5) with the Quick Link (29). Close the
Quick Link by turning the quick link nut.
Attach the other end of the Chain (28) to the
hook on the Backrest Frame (6) with the Clip
(27). Make sure that the Quick Link (29) is
attached to the Front Leg Frame and that
the Clip is attached to the Backrest Frame.
Make sure that all parts are properly tight-
ened before you use the inversion system.
27
5
29
Bracket
28
6
Closed Open
13
