Page 19: Ac power, Table 1.10, Table 1.11, Table 1.12, Table 1.13
www.wegener.com
800092-01 Rev. A
9
Unity 552 User’s Manual
Serial Port
Table 1.10: iPump 562 Serial Port
Local Hard Disk Driver (HDD)
Table 1.11: iPump 562 HDD
LNB DC Power (RF Port 1 ONLY)
Universal and Standard LNB Supported. See Astra PTS403d.
Table 1.12: iPump 562 LNB DC Power (RF Port 1 ONLY)
AC Power
Table 1.13: iPump 562 AC Power
Serial Port
RS-232
RJ11
Selectable services
Auxiliary character-based async output E-mail
character-based async output Terminal monitoring and
control
Baud Rates
2400 to 115200 baud
Formatting
8 data-bits, one start, one stop-bit, half-duplex, no parity
Local Hard Disk Driver (HDD)
Storage Capacity
8 GB
Interface
IDE
LNB DC Power (RF Port 1 ONLY)
Voltage
Standard: 18VDC Universal: 13 or 18 VDC, for LNB
polarity selection
22 KHz tone
22 kHZ control tone, for LNB DRO baud selection,
Universal mode
Current
350 mA max
Short-circuit protection
Thermal Fuse and Foldback Regulator
AC Power
Voltage
External 100-240 auto-detect/selected
Frequency
50 or 60 Hz +/-2%
Power consumption
30 watts with full LNB DC load
