Page 61: Optional lens
– 49 –
D
D
D
L
L
L
P
P
P
P
P
P
r
r
r
o
o
o
j
j
j
e
e
e
c
c
c
t
t
t
o
o
o
r
r
r
–
–
–
U
U
U
s
s
s
e
e
e
r
r
r
’
’
’
s
s
s
M
M
M
a
a
a
n
n
n
u
u
u
a
a
a
l
l
l
Audio speaker
Two 3W stereo speakers
I nput Connectors
Input Data 1
DVI-D (with HDCP)
Input Data 2
BNC x5
Input Data 3
DB-15
Video
(RCA x1)
S-Video
x1
Component Video
Through BNC-to-RCA adapter x3
HDMI Digital Video
x1
Input Audio 1 (RCA R/L)
RCA Jack (R/L) x 3 for Video, S-Video, Component
Input Audio 2 (Mini jack)
Mini Jack x 3 for Data DB-15, DVI, BNC
O
utput Connectors
Data output
DB-15 (Loop through)
Audio output
Mini jack for analog
C
ontrol Connectors
USB
Type B x1
RS-232
DB-9 x1
Network Control (RJ45)
RJ45 for assets management w/ embedded web server
Option for wireless
RJ45 x1, mini PCI 802.11b/g
O
ptional Lens
Model
Throw ratio
GR-1
0.8:1
G-80
1.5 - 1.8: 1
Standard lens
1.8 - 2.25: 1
G-200
G-400
G-500
2.25 - 3.0 : 1
3.0 - 4.5 : 1
4.5 - 7.0: 1
