Page 26
2-4 User’s Reference Guide
Netopia R2020 Dual Analog Router Back Panel Ports
The figure below displays the back of the Netopia R2020 Dual Analog Router.
Netopia R2020 Dual Analog Router back panel
8
Ethernet
Normal/Uplink
Auxiliary
Console
Power
4
7
3
6
2
5
1
Line 2
Line 1
1
8 por t Ethernet hub
Crossover switch
Line por ts
Auxiliar y por t
Console por t
Power por t
