Easy Setup 6-31
Quick Easy Setup Connection Path
This section may be all you need to do to configure your Netopia 4652 SDSL/IDSL Router. Your ser vice provider
will supply you with several parameter values. Below is a handy checklist:
DSL Line Configuration Screen
Line type
❑
SDSL-ATM (default)
or
❑
SDSL-HDLC
or
❑
IDSL (requires reboot)
(for SDSL-ATM only)
Operation Mode:
❑
Generic
❑
Lucent
❑
Nokia EOC Fast
❑
Nokia Fixed
❑
Paradyne
❑
Nor tel UE IMAS
Data Rate:
_______________________
Data Link Encapsulation
❑
PPP (default)
or
PPP Mode:
❑
VC Multiplexed (default) or
❑
LLC SNAP
❑
RFC1483
or
RFC1483 Mode (SDSL-ATM Line
Type only):
❑
Bridged 1483 (default) or
❑
Routed 1483
(for Bridged 1483 only)
PPP over Ethernet (PPPoE)
❑
Off (default) or
❑
On
(for SDSL-HDLC and ISDL
Line Types only)
❑
Frame Relay
or
PPP over Frame Relay Enabled:
❑
Off (default) or
❑
On
DLCI:
_______________________
LMI:
❑
ANSI (Annex D)
❑
CCITT (Annex A)
❑
LMI
❑
None
(for ISDL Line Type only)
❑
HDLC
Data Circuit VPI
Data Circuit VPI 0-255 (0 is default)
0-65535 (38 is default) _______________________
_______________________
Easy Setup Profile Screen
Address Translation
Enabled:
❑
Yes (default) or
❑
No
IP Addressing:
❑
Numbered (default) or
❑
Unnumbered
(for Numbered IP Addressing)
Local WAN IP Address:
_______________________
Local WAN IP Mask:
_______________________ (for Unnumbered IP Addressing)
Remote IP Address:
_______________________
Remote IP Mask:
_______________________
(for PPP DLEs only)
PPP Authentication:
❑
None (default),
❑
PAP or
❑
CHAP
(for PAP or CHAP)
User Name (or Host Name):
_______________________ (for PAP or CHAP)
Password (or Secret):
_______________________
