NT8D41AA Serial Data Interface Paddle Board Page 673 of 906
Circuit Card Description and Installation
Option switch settings
Address
Address select switch SW4 and logic on the card always address the two
UARTs using a pair of addresses: 0 and 1, 2 and 3 through 15 and 16. The
settings for this switch are shown in Table 212.
Baud rate
Switches SW2 and SW3 determine the baud rate for each individual port. The
settings for these switches are shown in Table 213 on
page 674 .
Table 212
SDI paddle board address switch settings
Address Switch SW4
Port 1 Port 2 1 2 3 4
0 1 off on on on
2 3 off on on off
4 5 off on off on
6 7 off on off off
8 9 off off on on
10 11 off off on off
12 13 off off off on
14 15 off off off off
