Panasonic BB-HCM381 - Manual (Page 177)

Operating Instructions
177
Camera Tilt Range (On the
ceiling) Not-selected - -
(Minimum) 0 degrees - 0 — +90
degrees,
current
(Home Position) +90 degrees - 0 — +90
degrees,
current
(Maximum) +90 degrees - 0 — +90
degrees,
current
Return to Specified
Position (Time) Do not move - Do not move,
10, 20, 30
(sec), 1, 5, 10,
30 (min), 1 h
(Specified Position) Home
Position
- Home Position/
Alarm No. 1, 2/
registered
preset number
and preset
name
Color Night View Disable - -
Vertical Resolution (for
640 x 480 mode) 480 - 480, 240
Audio Output Enable - -
Volume Standard - Minimum/
Standard/
Maximum
PC Audio Input
Timeout 1 min - 1, 2, 3, 5, 10,
20, 30, 60
(min)
Input Enable - -
Camera Microphone
Sensitivity Standard - Minimum/
Standard/
Maximum
Mute during Pan/Tilt Enable - -
Items Default Required Note
