19 VX4600 18 VX4600
The Battery
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time. The battery charge
level is shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the bottom of the battery
into the opening on the back of the phone. Push the
battery down until the latch clicks.
Removing the Battery
Turn the power off. Lift the release latch to detach
the battery.
NOTE: It is important to fully charge the battery
before initial use of the phone.
Charging the Battery
The desktop charger has a charging slot that accommodates
the phone with the battery attached or the battery by itself.
Warning! Use only the desktop charger provided
with the phone. Using any (desktop) charger other
than the one included with the VX4600 may damage
your phone or battery.
1. Plug the charger into a wall outlet. The phone
must be charged from a 120V AC power source.
2. Insert the phone with an installed battery, or the
battery by itself, into the charging slot. The red
light indicates the battery is charging and the
green light indicates the battery is fully charged.
The charge time varies depending upon the
battery level. The maximum charge time for a
fully discharged battery is 3 hours.
Battery Charge Level
The battery charge level is shown at the top right of the
LCD screen. When the battery charge level becomes
low, the low battery sensor alerts you in three ways:
sounding an audible tone, blinking the battery icon, and
displaying LOW BATTERY WARNING! If the battery
charge level becomes exceedingly low, the phone
automatically switches off and any function in progress
is not saved.
Fully Discharged Fully Charged
Getting Y Getting Y our Phone Star our Phone Star ted ted
Release
latch
Slot
