Piaggio 250 i.e. - Manual (Page 84)

Kerb weight 224 ± 5 Kg
bearing 410 kg
Max. speed 125 km/h
Air filter Sponge impregnated with fuel
mixture (50% SELENIA air filter oil
and 50% unleaded petrol).
Fuel tank capacity Tank capacity: ~12 l (approximate
value)
Fuel reserve ~ 2.0 l (approximate value)
Cooling circuit Capacity: ~ 2.0 l
Rear hub oil 250 cc
Exhaust muffler Twin three-way catalytic converter
MP3 250 I . E . E NGINE SPECIFICATIONS
Engine single-cylinder four stroke
Bore x stroke 72 x 60 mm
Cubic capacity 244.29 cm³
Compression ratio 10.5 - 11.5 : 1
Ignition advance (before TDC) variable (integrated into the ignition
system)
Spark plug CHAMPION RG 4 PHP
Valve clearance intake: 0.10 mm
discharge: 0.15 mm
Engine oil Capacity: 1.3 l (dry) ; 1.2 l (when
changing oil and filter)
84
4 Technical data
