Chapter 3 Basic Operation
Chapter 3 Basic Operation
3-43
4
Watching the composite image on the program monitor, turn the
F3(Hue) and F2(Sat) knobs, until the boundary between the
background image and foreground image provides a natural match of
hue and saturation.
Creating a composite image with a semi-transparent foreground image (density function)
You can make the inserted image semi-transparent, and insert it into the
background image.
Use the following procedure.
1
In the TITLE section of the menu control section, press the CRK
button, turning it on, to display page 2 of the chroma key menu.
The following example appears when the CRK button in column 1 is
lit.
T1CRK
2/3
COLCAN
ON
Sat
0-100
Hue
0-99
Densty
0-100
FILL
VIDEO
PAGE F1 F2 F3 F4 F5
2
Watching the composite image on the program monitor, turn the
F5(Densty) knob, to adjust the transparency of the inserted image.
