- 6 -
4. Appliance description
Ạ Overview
q
PLAY/PAUSE button:
Start/Suspend playback
w STOP button: Stop playback
e DVD/USB/CARD button:
Set the DVD, USB or CARD mode
r IR : Infrared sensor for the remote control
t Right loudspeaker
y Swivel joint
u NEXT button: next Title/chapter
i PREV button: previous Title/chapter
o VOL+ button: Volume increase
a VOL- button: Volume decrease
s SETUP button: Access the Setup menu
d OK button: Confirm input
f Navigation buttons :
Select menu input
g OPEN button: Open the disc tray
h Disc tray
j Left loudspeaker
k POWER : Operation LED
l TFT-Display
ạ Front panel
;
USB connection
Ả Right side
2)
SD/MMC/MS Card slot
2! 3,5 mm Headphones output
2@ AUDIO IN/OUT COAX : Audio Input/output,
co-axial output
2# VIDEO IN/OUT : Video Input/output
2$ DC IN 9-12 V : Input for power adapter
2% POWER switch: Device on/off switch
ả Remote control
2^
IR Sender
2& AV button: Select video input
2* DVD/USB/CARD button:
Set the DVD, USB or CARD mode
2( Number buttons 0-9 and button 10+
3) TIME button: Select a determined Title/chapter or
a determined time on the disc
3! SETUP button: Access the Setup menu
3@ STEP button: Individual frame playback
3# FUNCTION button: Access display settings
3$ REPEAT button: Repeat function and random play-
back settings
3% A-B button: Repeat chapter
3^ ZOOM button: Enlarge/reduce image size
3& SLOW button: Slow motion setting
3* button: previous Title/chapter
3( button: next Title/chapter
4) VOL- button: Volume decrease
4! VOL+ button: Volume increase
4@ Battery compartment (on the front panel)
4# button: Start/Suspend playback
4$ button: Stop playback
4% button: Search backwards
4^ button: Search forwards
4& RETURN/CLR button: One menu back/input
delete
4* MARK button: Place a bookmark
4( MENU/PBC button: Access the disc menu
5) TITLE button: Access the title menu
5! Navigation buttons :
Select menu input
5@ ENTER button: Confirm input
5# ANGLE button: Set camera position
5$ AUDIO button: Set the audio language
5% SUBTITLE button: Set the sub-title
5^ DISPLAY button: Display playback information
5& MUTE button: Switch off sound
5* PROG button: Programme playback ordern
