Front View
1. Port Selection Buttons
• Press a switch for less than two (2)
seconds to bring only the KVM focus
to the computer attached to its
corresponding port
• Press a switch for longer than two
(2) seconds to bring the KVM, USB
hub, and Audio focus to the
computer attached to its
corresponding port
• Press switches 1 and 2
simultaneously for two (2) seconds
to start Auto Scan Mode.
• Press switches 3 and 4
simultaneously for two (2) seconds
to perform a keyboard and mouse
reset
1
2 3
2. Port LEDs
The Port LEDs are built into the Port Selection Switches. The
upper ones are the KVM Port Status LEDs; the lower ones are
the USB Peripheral Selected LEDs:
KVM Status LEDs: Lights DIM ORANGE to indicate that
the computer attached to the corresponding port is up and
running (On Line); lights BRIGHT ORANGE to indicate that
the computer attached to its corresponding port is the one
