I-Tech Company WBX-6200F-V User Manual
Page 60
51
PIN No.
Name
Description
6
R Return
Red ground
7
G Return
Green ground
8
B Return
Blue ground
9 +5V
+5VDC
10 SGND
Sync
Ground
11 NC
Not
connected
12 SDA DDC
Serial Data Line
13 HSYNC Horizontal
Sync
14 VSYNC
Vertical
Sync
15
SCL
DDC Data Clock Line
16 NC
Not
connected
Inverter power connector (J7)
PIN No.
Name
Description
1 VCC
+12V
2 VCC
+12V
3 VEEON Backlight
Enable
4 LCD_
ADJ Brightness
control
5 GND
Ground
6 GND
Ground
Touch Pad Interface (J8)
Signal Description
PIN No.
8-wire 4-wire 5-wire
1 Right
Sense
N/A
N/A
2 Left
Sense
N/A
N/A
3 Bottom
Sense
N/A
N/A
4
Top Sense
N/A
Sense (S)
5 Right
Excite
Right
LR
(X)
6 Left
Excite
Left
LL
(L)
7
Bottom Excite
Bottom
UR (H)
8
Top Excite
Top
UL (Y)
9
Ground Ground Ground
Mini-PCI Slot (J9)
PIN No. Signal Description PIN No. Signal Description
