Analogue Module
The Analogue module provides the capability to monitor,
report and action on analogue values within a Concept
system. This module can be programmed to operate an
auxiliary when an analogue level from one or more of its
independent analogue inputs exceeds or goes below a
pre-programmed trigger point. Analogue levels can be
monitored and/or controlled in scaled units at any LCD
Terminal or remotely off-site.
Up to 99 Analogue Modules can be connected to a single
Control Module.
995088 Analogue Module (Voltage Mode)
in metal enclosure
995088C Analogue Module (Current Mode)
in metal enclosure
995088PCB&K Analogue Module short form kit
(Voltage Mode)
995089 Serial Temperature Sensor for
Analogue Module
LAN Power Supply
The LAN Power Supply is a dual 2A supervised power
supply producing 4A split evenly between system power
and dedicated battery charging. Up to three additional
LAN Power Supplies can be slaved to one LAN Power
Supply. Each slave can be configured differently to tailor
power output to system requirements. Ganged LAN Power
Supplies come into their own in installations where express
charging of large back up battery banks is needed.
995050AU LAN Power Supply in metal enclosure
995050PCB LAN Power Supply (PCB only)
2A Power Supply
Specifically designed and tested for compatibility with
proximity type reader heads, the 2A Power Supply can be
used wherever battery backed 12V supplies are required to
power Concept modules, detectors, readers and auxiliary
devices such as strobes, sounders, locks, etc.
994055 Short form 2A Power Supply (PCB only)
Power Supply Accessories
560007 3A transformer
999004 16VAC 1.5A plug pack (Allows 994055
to be used as a 1A power supply)
994053 16VAC 2.5A in-line plug pack
999000 IR Fuse Pack
605049 400mm cable for direct connection to 2
Door Access Module or Mini Expander
Enclosures & Accessories
Designed for our Concept 4000 Module PCBs, the Low
Profile Metal Enclosures present a modular, application-
oriented solution to suit a variety of installation
requirements. The Low Profile Enclosures minimise
necessary wall space and simply the practice of selecting
and installing enclosures. Powered and un-powered
versions of each kind of enclosure are available. Four sizes
of mounting plates enable many combinations of associated
module PCB types to be installed within the same enclosure.
To complement the Low Profile Metal Enclosures, there are
a number of other enclosures to suit different purposes.
Fittings to assist with installation are also available.
990045WH Plastic Enclosure (Off White)
995200 Small Low Profile Enclosure
995200PE Small Powered Low Profile Enclosure
995201 Medium Low Profile Enclosure
995201PE Medium Powered Low Profile Enclosure
995203 Xtra Large Low Profile Enclosure
995203PE Xtra Large Powered Low Profile Enclosure
999002 PCB Mounting Clip Pack
999005 IR Fixing Pack
926005 Universal Battery Bracket
926017 17AH Battery Bracket
990050 External Weather Resistant
Terminal Housing
650003 Key Lock to suit Weather Resistant
Housing
995512 2 Door Acc Mod Equipment Box
Interface Cables
A range of pre-assembled interface cables are available for
connection to various serial devices and third party systems.
993009 DB9 Interface for Laptop
993025 DB25 Interface for PC’s
993026 Printer Interface Cable
993027 Modem Interface Cable
993030 Port 0 Interface Cable
993031 MODBUS Port 0 Cable
993028 LAN Ancillary Cable
608204 FE3000 Programming Lead
993035 Securitel / SpreadNet® Cable
994091 GSM Modem Interface Cable
994092 FE3000/GSM Modem Interface Cable
for FE3000
993013 C-Bus/HPM Interface Cable
993032 Dynalite Interface Cable
Surge Diverters
Where Concept 4000 hardware is installed in locations and
environments where a very high level of electrical transient
activity might be anticipated, the addition of Inner Range
Advanced Surge Protection Devices adds a further layer of
transient protection.
995040 Low Voltage AC and Battery Surge Diverter
995041 Inner Range LAN Surge Diverter
995042 PSTN (Telecom) Line Surge Diverter
Training & Demo Units
The portable Demonstration Units are an invaluable aid
for demonstration, training or for prototyping. Fitted in a
‘photographers case’, the self-contained unit comprises of
a Concept 4000 Control Module, Elite Terminal and 2 Door
Access Module along with proximity and swipe readers.
There are a number of three position switches connected to
various inputs as well as LEDs to indicate status of outputs.
998050 General Briefcase Demo Unit
IR-Secure 40 Format Readers, Cards and Fobs
994700 IR Dual-format Prox Card Reader
(Factory configured for IR-Secure 40 format)
994602 IR-Secure 40 Clamshell Prox Card*
994600 IR-Secure 40 ISO Prox Card*
994601 IR-Secure 40 Key Fob*
994602RS IR-Secure 40 Clamshell Prox Card*
(Registered Site)
994600RS IR-Secure 40 ISO Prox Card*
(Registered Site)
994601RS IR-Secure 40 Key Fob* (Registered Site)
*Please consult Inner Range for more details prior to purchasing items
marked with an asterisk.
Sundries
Short Form Catalogue
995083M 2 x 10A Relay Board (Connected strip of 8)
995083S 2 x 10A Relay Board
995084 8 x 5A Passive Relay Board
995085 1 x 2A DPDT Relay Interface
508001 Terminal blocks 2way
508002 Terminal blocks 8way
995910 LAN Hub Board 8way with DET+ & 0V Hub
995911 LAN Hub Board (breakaway version)
910034 Replacement Tamper Switch Actuator for
Elite Terminal (Ivory)
910034WH Replacement Tamper Switch Actuator for
Elite Terminal (White)
999002 CE Mounting Clip Pack
999005 IR Fixing Pack
999000 IR Fuse Pack
631022 Concept 4000 Programming Ref &
Installation Manual
630026 Concept 4000 User Manual
990010 Swipe Card Reader
650001 2000 Magnetic Swipe card
993011 3000 / 4000 Magnetic Swipe card –
(Programmable Site Code)
