Terminals
Elite Terminal
The Elite LCD Terminal is the main user interface for the
Concept 4000 system. Its 20 key backlit keypad and backlit
LCD display allows the user to easily perform typical user
operations, review system activity and program all options.
The LCD display allows the use of plain text to guide the
user through operations and identify alarms, events and
items by name.
995000U Universal Elite Terminal (ivory)
995000UWH Universal Elite Terminal (white)
993000 Concept 2000/3000 Bi-Lingual Terminal
Weatherproof Terminal
Sporting a stylish, waterproof, dust proof and vandal
resistant brushed aluminium case, the Weatherproof
Terminal from Inner Range adds yet more versatility to
the Concept 4000 stable of security and access control
products.
This device is perfect for gate or door access control in
exposed environments. In addition to 1 door access control,
users can also separately arm and disarm their alarm
system or a portion thereof using the Weatherproof Terminal.
Along with the area control, there is visible feedback
of “valid / invalid PIN” entry as well as “area armed /
disarmed” status.
995010 Weatherproof Terminal (Short form kit
containing keypad and reader module
PCB. Requires external power supply).
Touchscreen Terminal
Ideal for installations utilising building automation features,
the Touchscreen Terminal presents the user with a 3.5”,
touch sensitive colour display and user-friendly, intuitive
interface. The user interface can be tailored to site
requirements by the installer.
Without having to ‘log in’ to the terminal, users can control
building automation features such as lights and heating/
cooling as well as specify the time these items stay on.
It is possible to have some or all building automation
features available only if a user submits a PIN to ‘log in’ to
the Terminal. Security functions like arming and disarming
the system require the user to input their PIN.
995022 Touchscreen Terminal (ivory)
995022CH Touchscreen Terminal (charcoal)
995022NOTRIM Touchscreen Terminal (ivory) – Fitted with
adhesive for custom face plate
995022CNOTRIM Touchscreen Terminal (charcoal) – Fitted
with adhesive for custom face plate
Terminal Emulator
The Terminal Interface opens pathways for connection
to and control of a Concept system by touch screens,
embedded controllers and custom software applications
using straightforward scripting.
The Terminal Interface operates by sending keystroke
commands to the Concept system as an LCD Terminal does.
In this way, authentication is still controlled by the Concept
Control Module, greatly reducing application development
time and cost.
995021 Terminal Interface
I/O Expansion & Lift Control
Universal Expander
The Universal Expander module provides an additional 16
zone inputs, 8 auxiliary outputs and 2 Siren drivers. This is
expandable to 32 zone inputs and 32 auxiliary outputs.
The Universal also supports advanced lift control features.
Up to 64 Universal Expanders can be connected to a Control
Module over the Concept LAN.
995004AU Universal Expander with plug pack
995004AUPS Universal Expander with transformer
995004PCB&K Universal Expander short form kit
Mini Expander
The Mini Expander module provides an additional 8
zone inputs and 8 auxiliary outputs. Exclusive to the
Mini Expander is a programmable de-bounce feature for
increased sensitivity to inputs such as hold-up buttons,
event counting and monitoring of electronic plant
equipment. The input counting feature enables accurate
monitoring of events and/or customer activity. Up to 99
Mini Expanders can be connected to a Control Module over
the Concept LAN.
995086 Mini Expander in metal enclosure
995086PCB&K Mini Expander and accessories. short
form kit
995086PS Mini Expander with power supply in
metal enclosure
Add-ons for Universal and Mini Expanders
Expander Boards are available for the Universal Expander to
add a further 16 zone inputs or 24 auxiliary outputs. Also for
the Universal Expander are Lift Interface Boards to provide
an interface to lift buttons. High and low voltage versions are
available.
8 Relay Expander Boards are available for Universal and Mini
Expanders. One 8 Relay Expander Board can be connected to a
Mini Expander, whereas up to three Relay Expander Boards can
be attached to a single Universal Expander.
995006 16 Zone Expander Board for Universal
Expander with surge protection
995007 24 Auxiliary Expander Board for Universal
Expander with surge protection
994020 Lift Interface Board for Universal Expander
994020HV High Voltage Lift Interface Board for
Universal Expander
995082E 8 Relay Expander Board
– Expander Module Version
995019 Relay Extension Cable
RF Expander
The RF Expander Module provides connectivity to the Visonic
range of wireless devices. The RF Expander Module allows
seamless functionality for up to 32 wireless zone inputs
and 4,000 users with key fobs. Wireless detectors reduce
installation time and cost, whilst key fobs provide secure
arming and disarming of the system as well as remote
operation of outputs such as lighting and doors etc.
A perfect solution for heritage listed buildings, detached
structures and difficult installation points.
995020 RF Module in plastic enclosure
