I.R.I.S. FLAME MONITORING SYSTEM P522 - Manual (Page 7)

IRIS MODEL P522 APPLICATION MANUAL
Page 7
IRIS CABLE
3 COND UCTO RS PLUS 1 COA X
3CO NDUCTORS : 16 AW G 19 S TRAND INS ULATED W ITH
CRO SS ED-LINKE D-P OLY ETHYLE NE .017 THK
CO LOR S: BLA CK-RED-GREE N
1 COAX : 16 AW G 19 S TRAND INS ULATED W ITH
CRO SS ED-LINKE D-P OLY ETHYLE NE .017 THK
CO LOR W H ITE
36 AW G B RAIDED SH IE LD 90% CO VE RA GE
W ITH .012 TH K JACK ET C OLO R BLACK
CABLED : POLY PROPY LENE FILLER S FO R ROUNDNE SS
JACK ET: CR OS SE D-LINK ED-POLYETHY LENE
STRIP 3/8“ TY PIC AL
GR OM ME T
FLAT WAS HER
CABLE ENTRY NUT
SH IELD *
CABLE
PR EPA RATION
1 3
/4“
(TYP)
CABLE
CABLE CLAM P
CO NNECTO R W ITH
RE AR COVE R REM O VED
INSULATE SHIE LD W ITH SHR INK
TU BING LEAVIN G 3/8“ STIC KING O UT
CO NNECTO R JACKSCRE W
FINAL AS SE M BLY
* C ABLE IS SHOW N W ITH SHIE LD
ALREA D Y RE M OVE D FROM W HITE W IRE
FIGURE 3 - WIRING AND ASSEMBLY - VIEWING HEAD
Optional LTA Adapter
