Appendix D – RS-485 Communication

RS-485 communication between the SmartSensor and PC may be established by using
the SeaLink +485 model #2102 RS-485 to USB converter by SeaLevel, along with the
standard 25-pin “D” female connector with the following pin out:

1: No Connection (N/C)

10: N/C

18: N/C

2: -485

11: N/C

19: N/C

3: -485

12: N/C

20: N/C

4: N/C

13: N/C

21: N/C

5: N/C

14: +485

22: N/C

6: N/C

15: N/C

23: N/C

7: GND

16: +485

24: N/C

8: N/C

17: N/C

25: N/C

9: N/C

Appendix E – Labeling

The following label, visible to all persons exposed to the transmitter, is provided on the
product unless SAR compliance can be demonstrated:

Warning: All persons must beat least 20 cm from antenna when
transmitter is operating to meet FCC RF exposure requirements.
