Intermec EasyCoder PD4—User’s Guide

Appendix B—Media Speciﬁcations

Tickets with Gaps

⇐ a ⇒ Media Width

Maximum:

118.0 mm (4.65 inches)

Minimum:

25.0 mm (1.00 inches)

⇐ b ⇒ Copy Length

Maximum:

8 dots/mm (203.2 dpi)

1270 mm (50 inches)

11.81 dots/mm (300 dpi) 558.8 mm (22 inches)
Minimum:

8 dots/mm (203.2 dpi)

5 mm (0.2) inches)

11.81 dots/mm (300 dpi)

5 mm (0.2) inches)

⇐ c ⇒ Detection Position

Variable:

0 to 57 mm (0 to 2.24 inches)

⇐ d ⇒ Detection Slit Length

The length of the detection slit (excluding corner radii) must be mini-

mum 2.5 mm (0.10 inches) on either side of the detection position (e).

⇐ e ⇒ Detection Slit Height

Maximum:

26.0 mm (1.02 inches)

Recommended:

3.0 mm (0.12 inches)

Minimum:

1.2 mm (0.05 inches)

Paper Type Setup

• Gap paper

Note:

Do not allow any perforation to break the edge of the

media as this may cause the media to split and jam the printer.
