1 Ensure that your Switches are correctly installed and that
you have the correct number of Matrix Cables for your con-
figuration. We recommend that the bottom unit in your
stack is the one that contains the Matrix Module.
2 Working first with the Switch that contains the Matrix Mod-
ule, attach a Matrix Cable to one of the ports on the Matrix
Module. Connect the other end of that cable to the matrix
port on the same unit. For your stack to operate as one
unit, you must do this.
3 Connect each of the remaining cables between the ports on
the Matrix Module and the matrix port on each unit.
4 Connect your power cord and power-up the stack.
Ordering Matrix Cables
Matrix Cables are available from your supplier:
Technical Specification
Obtaining Support
For further information on obtaining support, refer to the
Technical Support information in the User’s Guide that
accompanies the switch, or visit our World Wide Web site
by entering the following URL into your web browser:
http://www.networking.ibm.com/support
Electronic Emission Notices
Federal Communications Commission (FCC)
Statement
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residen-
tial area is likely to cause harmful interference, in which
case the user will be required to correct the interference at
his own expense.
Properly shielded and grounded cables and connectors (IBM
P/N 02L0883 or its equivalent) must be used in order to
meet FCC emission limits. IBM is not responsible for any
radio or television interference caused by using other than
recommended cables and connectors or by unauthorized
changes or modifications to this equipment. Unauthorized
changes or modifications could void the user's authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Product Title Part Number
IBM 8271 Nways Matrix Cable 02L0883
Operating Temperature 0° to 50°C (32° to 122°F)
Storage Temperature –10° to 70°C (14° to 158°F)
Operating Humidity 10 to 95% non-condensing
Power Consumption (@ 5V DC) 800mA maximum (4W maxi-
mum)
Standards:
Safety
EMC
Emissions
Immunity
Environmental
UL 1950
EN60950
CSA22.2#950
EN55022 Class B, FCC Part 15 Subpart
B Class A, ICES-003 Class A, AS/NZS
3548 Class B, VCCI Class B,
EN50082-1
EN60068 (IEC 68)
