Washer-Extractors
24
5-08-53
Figure 15
Mounting Bolt Hole Locations - Model IHF165
CHM2179N
Figure 16
CHM2179N
3.19 in.
(81 mm)
44.80 in.
(1138 mm)
1.73 in.
(44 mm)
51
.1
4 i
n
.
(1299
m
m
)
46.
65 i
n
.
(1
185 mm
)
2.76 in.
(70 mm)
51.18 in.
(1300 mm)
64.72 in.
(1644 mm)
