IPSO CHM2172N - Manual (Page 20)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Washer-Extractors
5-08-53 19
Machine Dimensions - Model IHF135
Figure 12
1 Ventilation Tub 6 Water Drain
2 Electrical Connections 7 Soft Water Connections .75 in.
3 Electrical Connection Soap Pumps 8 Warm Water Connections .75 in.
4 Main Switch 9 Hard Water Connections .75 in.
5 Steam Connection .5 in. 10 Connection of the Liquid Soap Hoses
CHM2186N
CHM2187N
75
.59
in.
(1
92
0 m
m
)
59.06 in.
(1500 mm)
40.94 in.
(1040 mm)
37
.8
0
in
.
(9
60 mm)
47.24 in.
(1200 mm)
4.53 in.
(115 mm)
4.33 in.
(110 mm)
46.65 in.
(1185 mm)
CHM2187N
CHM2186N
CHM2188N
12.01 in.
(305 mm)
8.46 in.
(215 mm)
9.25 in.
(235 mm)
27
.36
in.
(695
mm)
7.28 in.
(185 mm)
2.17 in.
(55 mm)
1.97 in.
(50 mm) 1
3
9
5
4
10
6
8.86 in.
(225 mm)
6.89 in.
(175 mm)
4.53 in.
(115 mm)
4.13 in.
(105 mm)
8.66 in.
(220 mm)
6.5 in.
(165 mm)
6.5 in.
(165 mm)
2.95 in.
(75 mm)
8.46 in.
(215 mm)
6.69 in.
(170 mm)
9.84 in.
(250 mm)
8
2
2
2
7
