IBM THINKPAD S05L-1270-01 User Manual
Page 338
When replacing
Attention:
1. The inverter card is very sensitive. Connect the
interface cable as shown. Flexing the inverter
card with too much force seriously damages the
card.
2. It is not safe to touch the inverter card connecter
A
. A loose or incorrect connection of the
connector can cause a serious problem.
326
IBM Mobile Systems HMM
