IR REMOTE CONTROL
1 LED
Indicator
This LED will be activated momentarily each time a button is pressed.
2 CV1, CV2
Selects the Composite 1 (CV1) or Composite 2 (CV2) input.
3
PC
Selects the VGA input.
4 HD1, HD2, HD3
Selects the HDMI 1 (HD1), HDMI 2 (HD2), or HDMI 3 (HD3) input.
5 CO1, CO2
Selects the Component 1(CO1) or Component 2 (CO2) input.
6 SV1, SV2
Selects the S-Video (SV1) or S-Video 2 (SV2) input.
Layout and Descriptions
NOTE: An Activity Indicator that fl ashes quickly while holding down
any one of the 16 buttons indicates a low battery. Replace the IR
Remote Control battery as soon as possible.
