Part identification chart – Gold's Gym XRT 75 GGSY69320 User Manual
Page 36
M10 x 207mm Bolt (61)
M8 Nylon Locknut (71)
M10 Nylon Locknut (87)
M8 Washer (90)
M6 Washer (97)
M4 Washer (142)
42.5mm Spacer (137)
25mm x 25mm Round Outer Cap (140)
25mm x 50mm Round Outer Cap (113)
12.5mm Spacer (89)
19mm Spacer (86)
30mm Spacer (124)
25mm Spacer (118)
40mm Spacer (141)
22mm Spacer (144)
M10 Washer (91)
M10 Thick Washer (143)
PART IDENTIFICATION CHART—
Model No. GGSY69320
R0303A
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
