17
RS-232 SERIAL CONTROL
RS-232 Features
RS-232 remote functions are used to control of this product’s features. Features
include input to output routing, EDID storage, EDID management, etc. These
functions are available only through the use of the serial port.
Functions Syntax
The syntax for each function is always the same:
Character as the start fl ag → Function name → Space ( _ ) as function name end
fl ag → Parameter 1 → Space → Parameter n → Carriage Return ( \r ) →
Sample:
#FunctionName_param1_param2_param3_param4...\r
Syntax is NOT case sensitive.
EDID Management
Function Description
#EDIDDSTOLO Read downstream EDID and stores into a Local EDID
#EDIDDSTOBA Read downstream EDID and stores in EDID Bank
#EDIDBATOLO
Read downstream EDID and stores in any Local Input
#EDIDDETOLO Sets Local EDID to Default EDID
#LOCKEDID Secures Local EDID
#LOEDIDTOLO
Load EDID fi le using serial port to one of the local memories
#PRLOEDID Read Input Local EDID and sends to serial port
#PRDSEDID Read downstream EDID and sends to serial port
#PRBAEDID
Read EDID from an EDID bank and sends to serial port
#PREDIDST Prints EDID details
