iii
Do not open the equipment
unless totally familiar with
electrical circuits and
service manual.
Only qualified personnel
should work inside the
equipment.
WARNING WARNING
Turn off the power at the mains switch-
board before beginning the installation.
Fire, electrical shock or serious injury can
result if the power is left on or is applied
while the equipment is being installed.
ELECTRICAL
SHOCK
HAZARD
Standard Steering
Observe the following compass safe
distances to prevent deviation of a
magnetic compass.
CAUTION CAUTION
Display unit
Receiver unit NX-7001
Safety information for the Installer
NX-700A
NX-700B
1.45 m 0.95 m
0.30 m 0.30 m
1.15 m 0.75 m
Attach securely protective
earth to the ship's body.
The protective earth is required
to the power supply to prevent
electrical shock.
