70 - Memory Upgrade Module
6 Align the memory upgrade module with the part side up. Align the connector edge of the memory upgrade
module with the connector slot in the compartment. Be sure the alignment keys line up with those in the slot.
7 Insert the memory upgrade module at a 45° angle. Press the connector edge of the module firmly down and
into the connector until it lodges under the retaining clip. You’ll hear a click when it is properly in place.
8 Replace the cover and reinstall the screws.
Figure 27. Opening the Memory Compartment Figure 28. Installing a Memory Module
Alignment Keys
T HE MEMORY UPGRADE MODULE IS NOT SOMETHING YOU ROUTINELY REMOVE FROM YOUR NOTEBOOK .
O NCE IT IS INSTALLED , YOU CAN LEAVE IT IN PLACE UNLESS YOU WANT TO CHANGE SYSTEM MEMORY
CAPACITY .
