153 - WLAN Specifications
WLAN Specifications
Specifications
Item Specification
Type of network The Atheros XSPAN AR5008E-3NX (802.11 a/b/g+draft n) WLAN device conforms to IEEE
802.11a, 802.11b/g, and 802.11n (draft-compliant), Wi-Fi based*.
The Atheros AR5006EXS (AR5BXB6) Mini-Card Wireless network cards conform to
IEEE802.11a, IEEE802.11b, and IEEE802.11g, Wi-Fi based*
Transfer rate (Automatic switching) 54 Mbps maximum data rate (IEEE802.11n to be determined)
Active frequency • 802.11n (draft): 2.4 GHz or 5 GHz
• 802.11b/g: 2400~2473 MHz
• 802.11a: 4900 ~ 5850 MHz
Typical operating distances** • 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft. (91 m) @ 6 Mbps
• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11n (draft): Estimated double the operating distance of 802.11g and 802.11a in
their respective frequencies.
Number of channels • 802.11a: 8 independent channels
• 802.11b/g: 11 channels, 3 non-overlapping channels
• 802.11n (draft):
2.4 GHz - 3 non-overlapping channels when Channel Bonding is not used; 2 non-
overlapping channels when Channel Bonding is used.
5 GHz - 12 non-overlapping UNII channels with or without Channel Bonding
Security Encryption Types - WEP, TKIP, AES***, WPA 1.0, WPA2, CCX compliant
Encryption Key lengths Supported: 64 bits and 128 bits 802.1x/EAP
Maximum recommended
number of computers to be
connected over wireless LAN
(during ad hoc connection) 10 units or less ****
