Climate Control System
FRONT CONTROL PANEL
REAR CONTROL PANEL
Except LX models
Fe
a
tu
re
s
197
MODE BUTTON
MODE
BUTTON
REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON
REAR PASSENGER
COMPARTMENT
TEMPERATURE
REAR PASSENGER
COMPARTMENT
TEMPERATURE
CONTROL BUTTONS
REAR PASSENGER
COMPARTMENT
TEMPERATURE
CONTROL BUTTONS
DRIVER’S SIDE TEMPERATURE
CONTROL BUTTONS
FRONT PASSENGER’S SIDE
TEMPERATURE CONTROL BUTTONS
2009 Pilot
