Quick Check® 890 User’s Guide 1 - 3
User LED Indications
Audio Sound
An audio signal (default ON) provides a quick indication if a scan passes or fails
the current test. You can change the pitch/volume of these beeps (see
Illumination Timer on page B-1). After a scan, one short, high pitch beep
indicates that the symbol passes an appropriate group of tests, while one long,
low pitch beep indicates that it fails.
Special Features
The QC890 Verifier supports the Reflectometer mode. In the Reflectometer
mode, the unit operates as a free-running reflectometer. See
"Reflectometer
Mode" on page 3-7 for additional information.
Physical Connections
A DC power barrel on the back of the unit connects to a power supply for external
power and battery charging.
The DB9 port on the unit connects to the pen wand, mouse wand, or customized
imager. Refer to
"Scanning Properly Using the QC3800V Linear Imager:" on
page 3-5 . If you are using any of these devices, refer to "Scanning Properly
Using a Pen/Mouse Wand" on page 3-3 for additional information.
The RJ45 ten pin connector provides the USB or RS-232 serial interface to the
host. Refer to
"USB Communication Interface" on page 2-1 and "RS-232 Serial
Communication Interface" on page 2-3 for details on connecting your unit.
LED Indication Cause
Green Solid Charging
Green Flash Good read
Red Solid Error condition
Red Flashing Low battery
