8
GB
The Controls
IMPORTANT
Before using your oven in the ordinary way,
ALWAYS make sure that the timer has been set to
MANUAL operation. Unless this is done, the main
oven cannot heat up. Before seeking assistance,
make sure this is done (refer to oven timer
operation).
MAIN OVEN TEMPERATURE CONTROL
Turn the control clockwise to set the oven thermostat
to the required temperature.
If the timer is set correctly an indicator light will
illuminate. This will remain on until the oven reaches
the required temperature. This light will then cycle on
and off as the thermostat maintains control of the
oven temperature.
TOP OVEN TEMPERATURE CONTROL
Turn the control clockwise to set the top oven
thermostat to the required temperature. An indicator
light will illuminate. This will remain on until the oven
reaches the required temperature. This light will then
cycle on and off as the thermostat maintains control
of the oven thermostat.
GRILL CONTROL
The grill control is designed to provide variable heat
control of either both grill elements on together or the
single left-hand grill element only.
To set the grill power turn the grill control to any
setting MIN - MAX, clockwise for FULL grill and anti-
clockwise for HALF grill.
COOLING FAN
A gentle flow of air will be blown below the control
panel when the grill control is used and after a short
period of time when the ovens are used.
Note: Whenever the appliance has been used, the
cooling fan may run on or restart itself after all the
controls have been turned off. This indicates that the
appliance is still warm.
A B C
Grill
Control
Top Oven
Temperature
Control
Timer Main Oven
Temperature
Control
Top
Oven
Pilot
Light
Grill
Pilot
Light
Main
Oven
Pilot
Light
(DQ47I/2 & DE47X/2)
