Installation
Installation
Lap Belt Installation
Short Route
Figure A illustrates a typical short route lap
belt installation.
WARNING:
•
Always use recline bar when installing
restraint in vehicle using short route with
vehicle lap belt.
•
Do not install this restraint using a
non-locking ELR vehicle belt, unless a
belt shortening clip is used. Refer to the
vehicle owner's manual for instructions
on correct use of vehicle belts with child
restraints.
1
Insert recline bar into holes on rear of
restraint (see page 20).
2
Place the child restraint in a forward
facing position on the vehicle seat.
3
Pull the vehicle belt out, then pass it through
the first belt slot, from the rear of the restraint
to the front (Fig. B).
4
Route the vehicle belt under the cover
then through the second belt slot,
from the front of the restraint to the
rear (Fig. C).
B
A
C
5
Verify that the vehicle belt is not
twisted, then buckle (Fig. D).
6
While kneeling on the restraint to push
it firmly into the vehicle backrest,
remove all slack from the vehicle belt.
7
Verify that the vehicle belt is tight and
the child restraint is secure (Fig. E).
Installation can be improved by the use of
the Versa-Tether
®
(see pages 18–19).
IMPORTANT:
•
Always use the Versa-Tether for
children weighing more than 50
pounds (22.6 kg).
Removal
Reverse installation procedure.
D
E
