Pipe system chart – haier AU422BIBAA User Manual
Page 16
Muf
fler
One-way
valve
Pipe system chart
14
Indoor unit
Outdoor unit
4-way
switch valve
Compressor
Indoor heat exchanger
Outdoor heat
exchanger
HEA
TING operation
COOLING operation
Note: The wiring diagram is pasted inside the unit.
Stop valve
Indoor heat exchanger
Compressor
Gas and
liquid
separator
Gas and
liquid
separator
Muf
fler
4-way
switch valve
14
