2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similar qualified person.
3. If the fuse on PC board is broken please change it with the type of T 3.15A /250VAC.
4. The wiring method should be in line with the local wiring standard.
1. Applicable ambient temperature range:
The machine is adaptive in following situation
5. The power cable should be:
H07RN-F 5G 4.0mm
2
( For series 522 (380-400V, 3N~, 50Hz)) ;
H07RN-F 5G 2.5mm
2
( For series 482, 422, 362 282 (380-400V, 3N~, 50Hz)) ;
H05RN-F 3G 6.0mm
2
(For series 282 (1PH,220-230V~,50Hz)) ;
H05RN-F 3G 4.0mm
2
(For series 242 (1PH,220-230V~,50Hz)) ;
H05RN-F 3G 2.5mm
2
(For series 182 (1PH,220-230V~,50Hz)) ;
The connecting cable should be H05RN-F 4G 0.75mm
2
All the cables shall have got the European authentication certificate. During installation,
when the connecting cables break off, it must be assured that the grouding wire is the last one
to be broken off.
6. The power cable and connect cable should be self-provided.
7. The breaker of the air conditioner should be all-pole switch; and the distance between its
two contacts should be no less 3mm.
8. The indoor unit installation height is at least 2.5m.
9. A leakage breaker must be installed.
Safety Precautions
Rated Maximum Minimum
27 32 18
19 23 14
35 43 10
24 26 6
20 27 15
14.5 -- --
7 24 -7
6 18 --
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 -5
24 26 --
20 27 15
14.5 -- --
7 24 -7
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
For *.EAA :
For *.ERA :
Cooling
Heating
Indoor
outdoor
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
