Hanns.G HC17 Series - Manual (Page 22)

User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 43.2cm(17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
LCD Panel Brightness 300cd/m 2 (Typical)
Contrast 700:1 (Typical)
Viewable angle 150
° (H) 135° (V)
Response time 8 ms
Video
R,G,B Analog Interface
Digital (Dual-Input Model) H/V TTL
Input H-Frequency 31KHz – 80KHz
V-Frequency 55 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play VESA DDC2B TM
ON Mode ≤43W
EPA ENERGY STAR ®
OFF Mode ≤1W
Audio output Rated Power 1.2W rms (Per channel)
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. :337.92mm
Ver. :270.34mm
Power Source 100~240VAC,50/60HZ
Environmental
Considerations
Operating Temp: 5° to 40°C
Storage Temp.: -20° to 65°C
Operating Humidity: 20% to 80%
Dimensions
382(W)×389(H)×198(D) mm
15.0”(W)×15.3”(H)×7.8”(D)
Weight (GW/NW)
5.1 kg / 4.1 kg
11.2 lb / 9.0 lb
Regulatory Compliance
CCC, UL,VCCI, C-TICK, TUV, BSMI, CE,
CB, FCC, CUL, TCO’99, NOM
***The above specification is subject to actual panel specification and is subject to change
without prior notice.
22
