Honeywell ST 3000 SMART TRANSMITTER STR93D - Manual (Page 14)

34-ST-03-57
Page 14
Reference Dimensions:millimeters
Inches
Seal
omitted for
clarity
Optional
external
ground
with meter
45.7
1.8
53.1
2.09
Removal
Clearance
for All Caps 82.9
3.26
With
Smart meter
Without
meter
94.9
3.74
65.1
2.56
Without
meter
23.5
.925
STR93D DP/I Remote Seal with Vertical Pipe Mount
Optional
external
ground
with meter
45.7
1.8
53.1
2.09
Removal
Clearance
for All Caps 82.9
3.26
With
Smart
meter
Without
meter
94.9
3.74
65.1
2.56
Without
meter
23.5
.925
STR94G LGP/I Remote Seal with Vertical Pipe Mount
Rotational
Lock
3.6
0.14
Plug
55.3
2.18
Optional
Meters
135
5.32
24273
Seal
omitted for
clarity
LP seal
omitted for
clarity
67
2.64
Rotational
Lock
3.6
0.14
Plug
135
5.32
55.3
2.18
Optional
Meters
3.69
93.6
Figure 20—Approximate vertical mounting dimensions for Remote Seal Transmitter
