Panel Type 24-inch Wide-Aspect Active Matrix TFT (thin film transistor)
Viewable Image Area 24 in (61 cm) widescreen; diagonally measured
Screen Opening
(W x H) 20.4 x 12.7 in (51.84 x 32.40 cm)
Panel Type TN
Aspect Ratio 16:10
Viewing Angle (typical) Up to 160° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness (typical) * 300 nits (cd/m 2 )
Contrast Ratio (typical) * 1000:1
Dynamic Contrast
Ratio (typical)
*
3000:1
Response Rate
(typical)
*
5 ms (on/off)
Pixel Pitch 0.270 mm
Backlight Lamp Life
(to half brightness) 40K hours
Color Gamut 72% color gamut (NTSC)
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
On Screen Display
(OSD) Controls Buttons or Switches OSD menu, OSD up, Source select/OSD down, Auto adjust/OK, Power.
(from left to right)
Languages English, French, German, Spanish, Italian, Netherlands, Japanese, S.
Chinese, T. Chinese and Brazilian Portuguese
User Controls Brightness, contrast, positioning, color temperature (6500k, 9300k,
custom), individual color control, serial number, display, clock, clock
phase, monitor management (power saver, sleep), factory reset
Signal Interface/
Performance Horizontal Frequency 24 to 76 kHz
Vertical Frequency 50 to 63 Hz
Native Resolution 1920 x 1200 @ 60 Hz (WUXGA), 16.7 Million pixels
Preset VESA Graphic
Modes (non-interlaced) 1920 x 1200 @ 60 Hz
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1600 x 1200 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz
1280 x 960 @ 60 Hz
1024 x 768 @ 60 Hz
800 x 600 @ 60 Hz
640 x 480 @ 60 Hz
Text Mode Not supported
Mac Mode Not supported
Sun Mode Not supported
Maximum Pixel Clock
Speed 200 MHz (analog input); 165 MHz (DVI and DP input)
User Programmable
Modes Yes, 25
Anti-Glare Yes
Anti-Static No
QuickSpecs HP Compaq LA2405wg 24-inch Widescreen LCD
Monitor
Technical Specifications
DA - 13444 Worldwide QuickSpecs — Version 1 — 10.5.2009 Page 2
