SKU 47016 For technical questions, please call 1-800-444-3353. Page 9
Assembly Drawing
Note: To order parts included in a lettered set, you must order the entire set.
Set A (Air Adjusting Valve Assembly) includes parts A1, A2, A3, A4, A5, 34.
Set B (Cup) includes 19, 20.
Set C (Lid) includes 22, 23.
Set D (Needle Valve Assembly) includes 14, 15.
Set E (Spray Assembly) includes 34, 35, 36, 37, 38, 39.
Set F (Air Valve Assembly) includes 24, 25, 26, 27, 28, 29, 30.
Set C (Lid)
Set B (Cup)
Set D (Needle Valve Assembly)
Set A
(Air
Adjusting
Valve
Assembly)
Set E
(Spray
Assy.)
Set F (Air Valve Assy . )
3 4 5 6 7 8 9 10 11 12 13
14
1
2
20
21
22
23
19
15 16
17 18
A1
A2
A3
A4
A5
34
24 25 26 27 28 29 30
34
35
36
37
38
39
40
41
42
31 32
43
44
