26
INSTALLATION
See pages 45 through 46 for instructions on these advanced
programming functions.
NOTE: The AVR 146 remote is preprogrammed to operate the
transport controls of Harman Kardon DVD players when the AVR
or the Video 2 (cable/satellite) or Video 3 (TV) source is selected.
You may change this punch-through programming at any time.
Step Nine – Turn On the AVR 146
Two steps are required the first time you turn on the AVR 146.
1. Gently press the Master Power Switch until the word OFF is no longer
visible. The Power Indicator above the two power switches should
light up in amber, indicating that the AVR is in Standby mode and is
ready to be turned on. See Figure 34. Normally, you may leave the
Master Power Switch in the ON position, even when the receiver is
not being used.
Figure 34 – Power Switches
2. There are several ways in which the AVR 146 may be turned on from
Standby mode.
a) Press the Standby/On Switch on the front panel. See Figure 34.
b) Press the Source Select Button on the front panel. See Figure 35.
Figure 35 – Source Select Button
c) Using the remote, press any one of these buttons: AVR, DVD/CD,
TAPE/The Bridge, HDMI 1/HDMI 2, VID1, VID2, VID3, AM/FM or
6CH. See Figure 36.
Figure 36 – AVR and Input Selectors
NOTE: Any time you press one of the Input Selectors on
the remote (i.e., DVD/CD, TAPE/The Bridge, HDMI 1/HDMI 2,
VID1, VID2 or VID3), the remote will switch modes so that it will
only transmit the codes programmed to operate that device. In
order to control the receiver, you will need to press the AVR
button to return the remote to AVR mode.
