P
ART LIST—Model
No. HRCR91082
R1
100A
10
Key
Qty
.
Description
No.
1
1
Main Frame
2
1
Seat Frame
3
1
Wheel Frame
Arm
4
1
Pedal Frame
5
1
Handlebar Swing
Arm
6
1
Handlebar
Assembly w/Foam Grip
7
4
M8 Nylon Jam Nut
8
2
5 lb. W
e
ight
9
2
Lock Collar
10
1
Long Link
Arm
1
1
1
Short Link
Arm
12
1
Seat Bracket
13
2
Pedal/Handle Pin
14
1
Seat Axle
15
1
W
heel
Mount Axle Assembly
16
1
M8 x 2.375” Wheel Bolt
17
1
M8 x 1.375” Bolt
18
2
M8 x 1” Bolt
19
1
Bumper Plate
20
1
Seat
21
1
Left Sideshield
22
1
Right Sideshield
23
2
Left Pedal
24
2
Right Pedal
25
5
Frame Endcap
26
1
Bumper Spacer
27
1
Rubber Wheel
Key
Qty
.
Description
No.
28
1
Swing Arm
Endcap
29
8
Medium Bushing
30
4
S
hort Bushing
31
2
2.5-pound W
e
ight
32
1
Middle Foam Grip
33
2
Foam Grip
34
1
Front Cover Panel
35
1
Monitor
36
1
Magnet w/Bracket
37
1
S
eat Knob
38
1
Seat W
asher
39
2
1.25” Square Endcap
40
4
1” Square Endcap
41
4
Pedal Plug
42
4
M12 x 5” Bolt
43
1
Seat Knob Bolt
44
2
M8 x 0.63” Seat Bolt
45
10
Fastener Base
46
1
Dual End Snap Button
47
8
3/8” Hat Cap
48
2
1” Round Endcap
49
6
Plastic W
asher
50
2
1
” x 2” Endcap
51
8
Rubber W
asher
52
10
Fastener Pin
#
1
User
’s
Manual
Note: “#” indicates a non-illustrat-
ed part. Specifications are subject
to change without notice. For
information about ordering
replacement parts, refer to the
back page of this manual.
