Huffy 1C4880-A01 - Manual (Page 22)

Assembly
CAUTION: If you accidently drop the seat post
into the seat tube, you may not be able to remove it.
1. Install post clamp on seat tube:
- Put the clamp on the seat tube. Push the clamp
[1] down so you can see 1/16 inch [2] of the seat tube
[3] above the clamp.
NOTE: Some post clamps are welded in position and
can not be moved.
- If the post clamp has a raised edge, make sure the
raised edge is against the top of the seat tube.
2. Assemble the seat to the seat post or seat pillar:
The bicycle may have a seat post or seat pillar. Determine
which style you have and follow the instructions.
Seat Post Style
- Put the seat post [10] fully through the seat clamp
[11]
- Tighten the seat clamp so the seat [12] stays on the seat
post
- If the seat clamp has a nut on each side, tighten both nuts
equally
Seat Pillar Style
- If the seat has a clamp attached, remove and discard the
clamp
- Put the seat rails [ ] between the seat clamp and tighten the clamp.
Seat
