QUICK START GUIDE
For more information on connecting and using your monitor, please be sure to read all instructions in this user
manual.
Supplied Accessories (including option)
User Manual AAA Size
Battery X 2
Power Cord* Remote Control
P# HL02562
HDMI Cable HDMI Cushion Wood Screw
(4 x 20) X 1
Terminal
Cover
Floor Stand
AS-LSZ0081
(Optional)
*For some countries, the type of power plug provided may be different from that depicted.
Connection
18 ~ 21
q
Connect the power cord to the rear panel.
w
Connect to external equipment.
Example 1: Connecting to PC
To insert D-sub 15 pin, tilt the monitor forward and bring the terminals into view. Two people are required
to hold the monitor and insert D-sub 15 pin safely. Be careful not to damage the panel.
*D-sub 15 and Audio cables are not included.
Example 2: Connecting to DVD player
1
*
*
Audio Cable
D-Sub 15
Tilt Forward
HDMI Cable
Power Cord
NOTE
The difference between
Floor Stand AS-LSZ0081
and AS-LSZ0082 is
color. AS-LSZ0081 is
black and AS-LSZ0082
is silver.
HDMI Cable
