Hayter Mowers Envoy Code 100C - Manual (Page 27)

41 Spring - Deflector 100009 1
42 Knob - HOC 100039 1
43 Ratchet - HOC 100040 1
44 Washer - Spring M8 100119 4
45 Grassbag - Fabric/base 100513 1
46 Frame - Grassbag 100016 1
47 Top - Grass Bag 100075 1
48 Screw - M6 x 20 100127 2
49 Bolt - Plastic Handlebar 100029 2
50 Fan - Motor Top 100019 1
51 Spacer - Rear Wheel 100030 6
52 Pin - Spring HOC 100042 1
53 Spring - Counter Balance 100080 1
54 Cleat - Cable 100105 1
55 Terminal Block 100077 1
56 Washer - Grip M10 100079 2
57 Grassbag - Assy 100502 1 Inc. 45,46 & 47
58 Cable - Tie 100023 4
59 Washer - M8 100106 4
60 Main Lead - 17m UK Assy 100135 1
61 Main Lead - 17m European Assy 100136 1
1.27
LIST PARTS
ITEM NO. QTY. DESCRIPTION PART NO. ITEM NOTE
100133 (0) 18/3/05 11:02 am Page 1.27
