Page 17 For technical questions, please call 1-800-444-3353. ITEM 98199
SAFETY
O
PERA
TION
M
AINTENANCE
SETUP
Part Description Qty
1 Bolt M6X25 2
2 Base 1
3 Extension Arm 2
4 Screw 2
5 Feet 4
6 Bolt M8X50 1
7 Bolt M5X10 4
8 Spring Washer 8
9 Flat Washer 4
10 Plate 1
11 Rub Slice 1
12 Pin 1
13 Spring 1
14 Pin 3X20 1
15 Handle 1
16 Plate 1
17 Pin 1
18 Pointer 1
19 Bolt M4X12 2
20 Bolt M4X8 9
21 Kerf 1
22 Plate 1
23 Plate 1
24 Bolt M8X30 1
25 Table 1
26 Flat Washer 1
27 Lock Nut 1
28 Rail 1
29 Flat Washer 8
30 Spring Washer 8
31 Bolt M6X30 4
32 Screw 1
33 Clamp 1
33 Screw 1
34 Bolt 1
35 Flat Washer 1
36 Pointer 1
37 Nut 2
38 Spring 1
39 Bend Arm 1
40 Flat Washer 2
41 Lock Nut 1
42 Washer 2
Part Description Qty
43 Bolt 1
44 Lock Handle 1
45 Lock Pin Spring 1
46 Bolt 1
47 Bolt M5X14 2
49 Oil Cover 2
50 Bearing 2
51 Rod 2
52 Mount 1
53 Line Button 2
54 Washer 2
55 Bolt M6X10 4
56 Limit Plate 1
57 Slide Lock Wing Screw 1
58 Handle Ball 1
59 Lock Spring 1
60 Lock Pin 1
61 Spring Pin 1
62 Cover Stand 1
63 Screw 1
64 Bolt 1
65 Washer 2
66 Lock Button 1
67 Link Pole Bolt 2
68 Link Pole 1
69 Brush Cover 2
70 Carbon Brush 4
71 Brush House 2
72 Motor House 1
73 Bolt 4
74 Brush House Spring 2
75 Stator 1
76 Screw 2
77 Block Circle 1
78 Bearing 1
79 Rotor 1
80 Bearing 1
81 Lock Button 1
82 Lock Button Spring 1
83 Spring Washer 2
84 Block Plate 1
85 Spring 1
Part Description Qty
86 Pin 1
87 Cover 1
88 Bolt M6X10 1
89 Bolt M6X20 2
90 Dust Pipe 1
91 Dust Collector 1
92 Screw 1
93 Lock Washer 2
94 Bearing 1
95 Spring Washer 1
96 Gear 1
97 Front Cover 1
98 Bearing 1
99 Output Axis 1
100 Key 4X13 1
101 Bearing Cover 1
102 Bolt 3
103 Inner Flange 1
104 Blade 1
105 Outer Flange 1
106 Screw M8X20 Left 1
107 Lock Nut 1
108 Small Cover 1
109 Large Cover 1
110 Washer 1
111 Bolt 1
112 Bolt M8X12 1
113 Spring 1
114 Blade Cover 1
115 Link Pole Plank 1
116 Switch 1
117 Bolt 2
118 Handle 1
119 Bolt 2
120 Bolt 2
121 Handle 1
122 Bolt 2
123 Press Plank 1
124 Power Wire 1
125 Rubber sheath 1
126 Handle 1
127 Spanner 1
128 Bearing 1
REV 11a
Parts List and Diagram
Parts List
