The main parts of your Double Oven
TOP OVEN TEMPERATURE
& GRILL SELECTION CONTROL
MAIN OVEN TEMPERATURE
& FUNCTION CONTROL
CLOCK & OVEN TIMER
OVEN LIGHT
GRILL PAN AND
FOOD SUPPORT
TOP OVEN
DOOR
OVEN LIGHT
INNER DOOR
GLASS
OVEN SHELF
DOOR
SWITCH
RATING PLATE –
Record the Model No. and the Serial No. on KEY
CONTACTS, back page.
GRILL SETTING
CONTROL
GRILL ELEMENT
STAY CLEAN LINER
OVEN FAN
STAY CLEAN LINER
MEAT PAN & ANTI-
SPLASH TRAY
INNER DOOR GLASS
MAIN OVEN
DOOR
❍ ❍
❍
