LDS33/LDS46 Decorative Shroud
E
D
A
C
B
LDS-BV Decorative Shroud
Catalog #
A B C D
in. mm in. mm in. mm in. mm
LDS33 36 914 36 914 8.5 216 11 279
LDS46 48 1219 72 1829 8.5 216 11 279
Catalog # A B C E E
LDS-BV
in. 26 12.5 15.5 22 23
mm 660 318 394 533 584
B
C
B
A
C
A
DTS134/DTS146 DTO134/DTO146 Decorative Caps
DTO134 A B C
in 34 20 24
mm 864 508 610
DTO146
in 46 22.7 26
mm 1168 576 660
DTS134
in 34 21.18 24
mm 864 538 610
DTS146
in 46 21.18 26
mm 1168 538 660
Heatilator • I100 • 35144 • Rev AG 7/12
CT56 Chase Top
TR11T/TR442 - Round Telescoping Termination Cap
ST1175/ST475 - Square Termination Cap
TCT1175 - Terra Cotta Cap
32-3/8 in.
(822 mm)
34-3/8 in .
(873 mm)
23 in.
(584 mm)
19 in.
(483 mm)
15-5/8 in.
(397 mm)
9-3/8 in.
(238 mm)
10-1/4 in.
(260 mm)
17 in.
(432 mm)
20 in.
(508 mm)
72 in.
(1829 mm)
36 in.
(914 mm)
2 in.
(51 mm)
13-3/8 in.
(340 mm)
