Hitachi CP-S860E User Manual
Hitachi Projectors

1
Liquid Crystal Projector
Model
CP-S860W/E
USER’S GUIDE
Thank you for purchasing the Hitachi liquid crystal projector. Please read this user’s manual
thoroughly to ensure correct usage through understanding. After reading, store this instruction
manual in a safe place for future reference.
Outline
This liquid crystal projector is used to project
various computer signals as well as
NTSC/PAL/SECAM video signals onto a
screen. Little space is required for installation
and large images can easily be realized.
Features
(1) Outstanding brightness
The UHB lamp and high-efficiency optical
system assure a high level of brightness.
(2) Partial magnification function
Interesting parts of images can be magnified for
closer viewing.
(3) Distortion correction function
Distortion-free images are quickly
available.
(4) Power zoom and power focus.
(5) P in P function
(6) USB jack
Before Use
3
Checking the package Contents
8
Names and functions of each part
8
Installation
12
Basic operations
13
Adjustments and functions
17
Connection to the vido signal
terminals
22
Connection to the RGB signal
terminal
22
Connecting to the USB
25
Connection to the CONTROL signal
terminal
26
Example of system setup
31
Cleaning the air filter
31
Lamp
32
Message table
32
When you think something wrong
33
Specifications
34
About the warranty and
after-service
35
