Page 31

DESCRIPTION PART NO. QTY
ITEM NOTE
42
Screw - Washer Hd Taptite
09575
3
43
Bush
340154
2
44
Screw - Taptite
09349
3
45
Screw
09634
2
46
Lever - HOC
480128
1
47
Ratchet Moulding HOC
480126
1
48
Throwplate - Main Body
480011
1
49
Screw - Taptite
09545
4
50
Bearing - Roller Housing
219102
2
51
Roller - Rear W/A
480151W
2
52
Spring Tension - Rear Axle
480133
2
53
Washer
09262
2
54
Screw - Taptite
09365
22
55
Bush - Oilite Roller
340129
2
56
Roller Freewheel - Rocket Band
340150
2
57
Spacer - Nylon
340149
2
58
Shroud - Freewheel
340168
1
59
Locknut
340163
1
60
Shaft - Roller
480032
1
61
Sprocket - 22 Teeth
480039
1
62
Frame - Rear Roller W/A
480159W
1
Inc. 113
63
Key - woodruff
5321
1
64
Circlip 1428
1
65
Washer 480097
4
66
Cover - Transmission
480043
1
67
Chain
486037
1
68
Rod - Connecting
480045
1
69
Plate - Securing
219037
2
70
Filler - Throwplate
480017W
1
71
Pulley - Sprocket Fixed Speed
480171
1
72
Belt - V APTO
480063
1
73
Washer
02575
1
74
Circlip
03096
1
75
Pulley - Jockey
219156
1
76
Washer - Starlock
0201086
2
77
Bracket - Idler Assy
480115
1
78
Belt Guide
480116
1
79
Pulley - Drive APTO
480038
1
80
Spring - Torsion Idler
480066
1
81
Bush
4452
1
82
Washer - M12 H.D.
09280
1
1.31
ITEM NO
481A PARTS LIST
